WAGO
KIT DE MEDICIÓN DE ENERGÍA PARA 65A / 3x230-400 V / Modbus-M-Bus / Push-in CAGE CLAMP® / Display LCD Iluminado / Bluetooth® / Clase B / IP51-IP20
Solo queda 1 producto
código fiscal: 41113600
Use this text to display some key features of the products
WAGO modelo: 879-3020
Contador de consumo energético MIDI certificado para medición directa de energía activa y reactiva en redes trifásicas. Equipado con tecnología Push-in CAGE CLAMP® con palanca para conexiones rápidas y seguras. Ofrece interfaces de comunicación Modbus y M-Bus, además de doble interfaz S0 para salida de pulsos. Display LCD iluminado para visualización completa de parámetros energéticos y configuración mediante controles táctiles o aplicación Bluetooth®. Diseñado para montaje en carril DIN con dimensiones compactas que optimizan el espacio en cuadros eléctricos.
Características Generales
- Tipo: Contador de consumo energético MIDI
- Conexión: Directa
- Corriente máxima: 65 A
- Tensión: 3 x 230/400 V
- Frecuencia: 50 Hz
- Interfaces: Modbus, M-Bus, 2x S0
- Display: LCD con luz de fondo
- Configuración: Controles táctiles y Bluetooth®
- Montaje: Carril DIN-35
- Clase de precisión: B (1%)
Contenido del kit.
Item Quantity |
Item Number |
Description |
|---|---|---|
1 |
2002-1292 |
End and intermediate plate; 0.8 mm thick |
1 |
2006-1292 |
End and intermediate plate; 1 mm thick |
1 |
2006-1692 |
End and intermediate plate; 1 mm thick |
2 |
209-109 |
Edge guards; for DIN 35 rail (7.5 mm high) |
1 |
210-112 |
Steel carrier rail; 35 × 7.5 mm; 1 mm thick; 2 m long; slotted; according to EN 60715; hole width 25 mm |
2 |
2202-1201 |
2-conductor through terminal block; with push-button; 2.5 mm²; with test port; suitable for Ex e II applications; side and center marking; for DIN-rail 35 × 15 and 35 × 7.5; Push-in CAGE CLAMP® |
1 |
2206-1204 |
2-conductor through terminal block; with push-button; 6 mm²; with test port; for Ex e II and Ex i applications; side and center marking; for DIN-rail 35 × 15 and 35 × 7.5; Push-in CAGE CLAMP® |
1 |
2206-1207 |
2-conductor ground terminal block; with push-button; 6 mm²; with test port; suitable for Ex e II applications; side and center marking; for DIN-rail 35 × 15 and 35 × 7.5; Push-in CAGE CLAMP® |
3 |
2206-1611 |
2-conductor fuse terminal block; with pivoting fuse holder; for 5 × 20 mm miniature metric fuse; with push-button; without blown fuse indication; for DIN-rail 35 × 15 and 35 × 7.5; 6 mm²; Push-in CAGE CLAMP® |
4 |
249-116 |
Screwless end stop; 6 mm wide; for DIN-rail 35 × 15 and 35 × 7.5 |
1 |
879-3020 |
Energy meter (MID25); for direct connection; 65 A; 3×230/400 V; 50 Hz; Modbus® and M-Bus; 2 × S0 interface; 4PS |
